Technologies

asymmetric rear arms

The drive-side chainstay has been modified to better facilitate the forces applied to it by the actuation of the drivetrain, providing enhanced stability and ultra-efficient power transfer.

Technologies

easy drive system

Wilier road bikes are famous for their front ends. Our integrated head tube and fork designs equate to unrivaled steerability for confident cornering and descending. The oversized, squared profile that characterizes our fork crowns and that flows into the base of our head tubes maximizes strength and stability at a key fulcrum point.

Technologies

Integrated drop out

Seamless construction that does away with joints, glues and bolts. The dropouts are part of the unified rear triangle and an essential component of the carbon monocoque frame mold. As part of the continuous seat and chainstays, the angles of this area of the frame structure have been relaxed to dissipate road vibrations and improve comfort as well as handling.

Technologies

LIT

We’ve also leveraged LIT (Large Inflation Tube) technology in the making of the Cento1 Superleggera. Our prepreg carbons benefit from even higher and more uniform compaction through the use of industrial, high pressure bladders. The bladders expand from within the frame’s tubing, pushing against the inner walls of the tubes as the frame mould exerts opposing pressure from the outside. The combined compaction- forces result in a precision, lower-void construction and consistent wall thickness of the tubes throughout the frame’s construction. More traditional carbon manufacturing processes fail to optimally compact a composite, resulting in varied wall thicknesses, or voids (undesirable resin deposits), along a frame’s tubing that compromise structural integrity. That could translate into reduced longevity and strength. So the advantages of the Cento1 SL’s construction are obvious: increased capacity to handle stresses, optimal torsional stiffness, and unparalleled responsiveness.

Technologies

BB 386

The BB386EVO system takes the oversized bottom bracket design concept, which was successfully introduced by Wilier Triestina in the Cento1 model and subsequent variations, to its next evolution. To obtain an unprecedented stiffness at a crucial point of the frame, we have devised an innovative system that can perfectly incorporate an ultra-stiff crank into an ultra-stiff frame. The traditional BB30 system proved inadequate because it requires a frame with a 68 mm box, which is too narrow to deliver the degree of stiffness that we wanted. With this in mind, we developed the new standard BB386EVO in collaboration with FSA, which pairs a carbon crank with a longer 30 mm spindle and a wider 86.5 mm bottom bracket box.

Technologies

Easy adjust

Wilier Triestina still insisted on a design that allowed for fine-tuning of rear wheel position and therefore of the cogset’s orientation in relation to the rear derailleur. This enables optimal wheel alignment, aerodynamic positioning and smooth shifting. Thanks to our innovative solution providing 6mm of adjustability, wheel base and distance from tire to the rear of our truncated seat tube airfoil are customizable. This enables both aerodynamic and bike handling optimizations, as well as making wheel changes fast and simple.
